Low Voltage Switchgear

PZ30 Distribution Box

PZ30 series is a device for installing terminal electrical appliances, which can be installed with various types of small circuit breakers, series of earth leakage circuit breakers, and fuses for power distribution, power metering, and control of electrical equipment. It adopts modular design, rail mounting, novel shape, beautiful and lightweight, compact layout of electrical components, flexible composition scheme, safe use, and convenient installation. It is suitable for AC 50Hz, rated voltage 230V, and 400V modular terminal circuits.

PREV: Ri4Power-ZN Low-voltage Switchgear NEXT:MLS-V Low-voltage Switchgear

Overview

Model Meaning

Product Overview

Product Implementation Standards

GB7251.3 Low-voltage switchgear and controlgear

IEC60439 Low-voltage Switchgear and Controlgear

IEC60529 Enclosure protection level (IP code) (GB4208-1993)

Equipment External Size Table

Total Number Of Circuits	Panel Height(mm）	Panel Width(mm）	Box Height(mm）	Box Width(mm）	Cabinet Depth(mm）	Note
4	175	165	155	135	80	Single-row
6	230	200	205	175	90	Single-row
10	300	300	265	265	90	Single-row
12	300	335	265	300	90	Single-row
15	300	390	265	355	90	Single-row
18	300	445	265	410	90	Single-row
20	500	300	465	265	90	Double-row
24	500	335	465	300	90	Double-row
30	500	390	465	355	90	Double-row
36	500	445	465	410	90	Double-row
45	620	390	585	355	90	Three-row

Ordering instructions:

★Primary circuit scheme, equipment model and capacity.

★Box surface colour.

★Installation method (open or concealed)

★If the user has futures requirements can be negotiated with the company.
